CITIZEN L25-VII – Year 1997
turning diameter over bed 25 mm
spindle passage 40 mm
turning length 250 mm
turning speeds 200-8000 U/min
c-axis 0,001 0
gripping station 25 mm
turning length 120 mm
turning speeds 200-8000 U/min
number of tools 5+3+4+5
number of milling stations 4
control Mitsubishi Meldas
positive location each 15 Grad
Number of axles 6 St.
chip conveyor lange Version kW
total power requirement 5,5 kW
weight of the machine ca. 2720 kg
dimensions of the machine ca. 2,5 x 1,3 x 1,8 plus FMB m
bar loader FMB 5-42
CNC-sliding head auto Citizen L 25-VII with bar magazine FMB 5-42 and
chip conveyor.
The Citizen L25 was purchased in 2018. However, the customer gave up
the production (lack of skilled workers). On the machine were
no parts have been produced so far.
Chip conveyor long, as option long parts. Finished parts will go through
the pick-up spindle
FMB 5-42 bar loader for 4m bars
Schlichting guide bush. This guide bush can use material with larger
tolerances. No grinded material necessary!
Mitsubishi service has checked the machine electrically, everything is ok.
