KEEPWAY KAIFENG MACHINERY KT-25LS CNC Machine Specifications
Origin: Taiwan
Category: Lathe CNC 10 Inch
| Item | KT-25LS |
|---|---|
| Controller | Fanuc 0i-TF Plus |
| Bed swing diameter | 530 mm |
| Saddle swing diameter | 380 mm |
| Maximum turning diameter | 360 mm |
| Maximum turning length | 750 mm |
| Bar capacity | 75 mm |
| Power chuck diameter | 10\" |
| Spindle motor power | 15 / 18.5 kW |
| Spindle speed | 3500 rpm |
| Spindle nose taper | A2-8 |
| Spindle bearing diameter | 120 mm |
| Spindle taper | 1/20 |
| X-axis travel | 180 + 30 mm |
| Z-axis travel | 750 mm |
| X-axis rapid feed rate | 20 m/min |
| Z-axis rapid feed rate | 20 m/min |
| Guide way type | Linear |
| Turret driven type | Servo |
| Tool capacity | 10T |
| OD tool shank size | 25 mm |
| ID tool shank size | 40 mm |
| Tailstock travel positioning | Hydraulic |
| Tailstock quill travel | 150 mm |
| Tailstock base travel | 675 mm |
| Quill taper size | MT#5 |
| Quill taper diameter | 85 mm |
| Floor space (L × W × H) | 4070 × 1705 × 1844 mm |
| Machine weight | 5200 kg |
