| TORNOS MULTIDECO 20/8 CNC Multi-Spindle Automatic Lathe – Year 2001 |
| Manufacturer |
TORNOS |
TORNOS |
| Model |
MULTIDECO 20/8 |
MULTIDECO 20/8 |
| Machine Type |
CNC Multi-Spindle Automatic Lathe |
CNC Multi-Spindle Automatic Lathe |
| Year of Manufacture |
2001 |
2001 |
| Control System |
TORNOS PNC DECO |
TORNOS PNC DECO |
| Specification |
Metric |
Imperial |
| Bar Diameter Capacity |
5 – 20 mm |
0.197 – 0.787 in |
| Maximum Workpiece Length (Without Counter Operation) |
100 mm |
3.94 in |
| Maximum Workpiece Length (With Counter Operation) |
80 mm |
3.15 in |
| Maximum Spindle Speed |
5,000 rpm |
5,000 rpm |
| Main Spindle Motor Power |
15 kW |
20.1 HP |
| Auxiliary Power |
3.7 kW |
5.0 HP |
| Counter Spindle Motor Power |
1.1 kW |
1.5 HP |
| Number of Numerical Axes |
23 |
23 |
| Number of Cross Slides |
8 |
8 |
| Long Slides |
7 |
7 |
| Counter-Operation Guide Slide |
1 |
1 |
| Counter Spindle |
1 |
1 |
| Bar Feeder |
IEMCA PRA 40/33F Bar Loading Magazine |
IEMCA PRA 40/33F Bar Loading Magazine |
| HIRTH Drum Lock |
Equipped |
Equipped |
| High-Pressure Coolant Pump |
Equipped |
Equipped |
| Chip Conveyor |
Equipped |
Equipped |
| Turning Tool Holder |
Included |
Included |
| Equipped With |
• TORNOS PNC DECO CNC Control
• HIRTH Gear Drum Lock System
• High-Pressure Coolant Pump
• Chip Conveyor
• Turning Tool Holder
• IEMCA PRA 40/33F Automatic Bar Loading Magazine
• Counter Spindle
• 23 CNC Numerical Axes
• 8 Cross Slides
• 7 Long Slides
• 1 Counter-Operation Guide Slide |
