| ETIS Galvanic Equipment
Automated Nickel-Chrome Electroplating Line – Completely Refurbished in 2025 |
| Specification |
Technical Data |
Remarks |
| General Information |
| Machine / Line Type |
Automated Nickel-Chrome Electroplating Line |
Industrial automated electroplating production line |
| Location |
contact to us |
Current location |
| Refurbishment |
Completely Refurbished in 2025 |
Seller supplied information |
| Current Condition |
Dismantled and Ready for Loading |
Operational before dismantling, according to the seller |
| Current Assembly Status |
Dismantled |
Historical photographs show the line before dismantling |
| Production Capacity |
| Coating Surface Area |
400–450 dm² |
Physical part dimensions not specified |
| Maximum Rack Load |
1,000 kg per rack |
Approx. 2,205 lb per rack |
| Production Capacity |
8,000 dm²/hour |
Approx. 861 ft²/hour |
| Electricity Consumption |
80 kWh |
Measurement period not specified in the source |
| Installation & Footprint |
| Installed Footprint |
40,000 × 6,000 mm |
40 × 6 m / Approx. 131.2 × 19.7 ft |
| Total Installed Area |
Approx. 240 m² |
Approx. 2,583 ft² |
| Nominal Tank Length in Schedule |
4,200 mm |
Approx. 165.35 in / 13.78 ft |
| Usable Part Dimensions |
Not Specified |
Not stated in the source documentation |
| Process Line |
| Number of Process Baths |
45 |
Confirmed by the seller |
| Equipment Schedule |
33 MAK Codes |
Several MAK codes group two or more individual baths |
| Automation Position Display |
Positions numbered through 45 |
Shown on the automation screen |
| Grouped Process Bath Schedule |
| MAK 01 |
Loading / Unloading |
Volume not applicable / not stated |
| MAK 02 |
Ultrasonic Degreasing |
3,658 L / Approx. 966 US gal |
| MAK 03 |
Hot Degreasing – Baths 1–2 |
7,098 L |
| MAK 04–05 |
Rinse Baths |
3,276 L each / Approx. 865 US gal each |
| MAK 06–08 |
Acid Degreasing – Baths 1–6 |
6,989 L per listed pair |
| MAK 09–11 |
Rinse Baths |
3,276 L each |
| MAK 12 |
Electrolytic Degreasing |
5,460 L / Approx. 1,442 US gal |
| MAK 13–14 |
Rinse Baths |
3,276 L each |
| MAK 15 |
Pickling |
3,276 L |
| MAK 16–18 |
Rinse Baths |
3,276 L each |
| MAK 19–21 |
Nickel Baths 1–6 |
11,193 L per listed pair |
| MAK 22 |
Activation |
5,187 L / Approx. 1,370 US gal |
| MAK 23 |
Chrome Baths 1–2 |
11,193 L per listed pair |
| MAK 24 |
Bisulfite Bath |
3,276 L |
| MAK 25–26 |
Rinse Baths |
3,276 L each |
| MAK 27 |
Deep Rinse |
3,906 L / Approx. 1,032 US gal |
| MAK 28 |
Drying Bath / Chamber |
Volume not stated |
| MAK 29–30 |
Stripping Baths 1–2 |
3,385 L each |
| MAK 31 |
Stripping Bath 3 |
2,566 L |
| MAK 32–33 |
Stripping Rinse Baths |
2,184 L each |
| Process Schedule Notes |
| Bath Grouping |
Several MAK codes represent two or more baths |
The 33 MAK codes are not an individual listing of all 45 process baths |
| MAK 32 / MAK 33 |
Both described as “Stripping Rinse Bath 1” in the source list |
Source description retained without correction |
| Nickel & Chrome Rectifiers |
| Nickel Rectifiers |
6 × 1,300 A, 15 V |
Included |
| Chrome Rectifiers |
2 × 4,500 A, 15 V |
Included |
| Additional Rectifier |
1 × 3,000 A, 15 V |
For electrolytic degreasing |
| Nickel Circulation Pumps |
| Nickel Pumps |
3 × MEFIAG Pumps |
Named in the equipment schedule |
| Maximum Flow per Nickel Pump |
30 m³/hour |
Approx. 132 US gal/min per pump |
| Automation System |
| Automation |
Automated Process Control System |
Historical interface screenshots supplied |
| Station Layout |
Automation Overview & Station Layout |
Displayed in control interface |
| Temperature Control |
Automated Temperature Control Screen |
Historical interface screenshot |
| Line Settings |
Multiple Line Setting Screens |
Historical interface screenshots |
| Robot Step Settings |
Programmable Robot Step Control |
Historical interface screenshot |
| Robot Travel Distance Control |
Programmable Travel Distances |
Historical interface screenshot |
| Robot Speed Control |
Programmable Robot Travel Speeds |
Historical interface screenshot |
| Travel Distance Settings |
Programmable Position / Distance Settings |
Historical interface screenshot |
| Vertical Motion Control |
Automated Vertical Movement Control |
Includes ultrasonic-related control shown in interface |
| Dosing Control |
Automated Dosing Control |
Multiple dosing units shown in interface |
| Pump Control |
Automated Pump Control |
Multiple pump units shown in interface |
| Rectifier Control |
Automated Rectifier Control |
Two historical rectifier control screens supplied |
| Reporting |
Automation Reporting Screen |
Historical interface screenshot |
| Material Handling & Transport System |
| Rack Handling |
Automated Overhead Transport System |
Historical installed-line photographs supplied |
| Overhead Carriers |
Included |
Shown operating above the process tanks in historical photographs |
| Transport Arrangement |
Overhead carrier system alongside process baths |
Historical photographs show original installed configuration |
| Equipment Included in the Sale |
| Process Baths |
Included |
| Filters |
Included |
| Rectifiers |
Included |
| Hot-Water Boiler |
Included |
| Purified-Water System |
Included |
| Dosing Pumps |
Included |
| Nickel Pumps |
3 × MEFIAG Pumps Included |
| Electrical Components |
Included / Shown in Current Seller-Supplied Photographs |
| Rectifier Cabinets |
Included / Shown in Current Seller-Supplied Photographs |
| Rack Components |
Refurbished Components Shown in Current Photographs |
| Ventilation Equipment |
Shown in Current Seller-Supplied Photographs |
| Cabling & Connection Points |
Shown in Current Seller-Supplied Photographs |
| Refurbishment & Current Equipment Documentation |
| Refurbished Line & Tank Assembly |
Current seller-supplied photograph available |
| Process Bath |
Current seller-supplied photograph available |
| Rectifier Cabinets |
Current seller-supplied photographs available |
| Electrical Components |
Current seller-supplied photographs available |
| Process Line Components |
Current seller-supplied photographs available |
| Refurbished Rack Components |
Multiple current photographs available |
| Ventilation Equipment |
Two current photographic views available |
| Historical Documentation |
| Installed Production Line |
Historical photographs available |
| Process Tanks |
Historical installed-line photographs available |
| Overhead Transport System |
Historical photographs available |
| Overhead Carriers & Bath Arrangement |
Historical photographs available |
| Filter & Rectifier Photographs |
Historical photographs available |
| Automation Interface Screens |
Historical screenshots available |
| Current Status & Buyer Responsibilities |
| Current Equipment Status |
Dismantled and Ready for Loading |
According to the seller |
| Operational Status Before Dismantling |
Operational |
According to the seller |
| Transport |
Buyer Responsibility |
Transport is not included |
| Commissioning |
Buyer Responsibility |
Commissioning is not included |
| Important Technical Notes |
| Part Dimensions |
Not Specified |
The stated 400–450 dm² figure refers to coating surface area, not physical workpiece dimensions |
| Tank Length |
4,200 mm Nominal |
Usable internal workpiece dimensions are not specified |
| Bath Count |
45 Process Baths |
Seller confirmed; equipment schedule is grouped under 33 MAK codes |
| Automation Screens |
Historical Screenshots |
Screens demonstrate the available control interface but do not independently verify present operation after dismantling |
| Installed-Line Photographs |
Historical |
Show the line before dismantling and do not represent its current assembled condition |
