DSHT DAESUNG HI-TECH NOMURADS 10EX2 CNC Machine Specifications
Origin: South Korea
Category: Lathe CNC Swiss Bar Capacity Ø10mm
| Items | Specification | Specification Value | Standard Accessories |
| Machining capacity | Max. machining diameter | Ф10mm | I.D. tool unit |
| Max. machining length | 110mm / 1 chuck | Tool holder | |
| Max. parts unloading length | 80mm | Rotary guide bush | |
| Spindle | Main spindle through-hole diameter | Ф13mm | Rotary guide bush drive unit |
| Spindle rpm (Main/Sub) | Max. 20,000rpm | Drill holder | |
| Sub spindle chucking diameter | Ф10mm | Main: Chuck sleeve / Spring / Spindle cap (1 set) Sub: Chuck sleeve / Spring / Spindle cap (1 set) | |
| Tool | Max. number of tools | 21 | Automatic power turn-off device |
| Max. machining drill | Ф7mm | Automatic oiling device (level detector attached) | |
| Max. machining tap | M6 | Cutting oil device | |
| Main – O.D. tool (□10×130mm or less) | 6 | Coolant failure detector | |
| Main – I.D. tool (ER11) | 4 | Overload detection function | |
| Main – Cross drill (ER11) | 3 | Door interlock switch | |
| Main – Cross drill rpm | Max. 10,000rpm | Working light (LED) | |
| SUB – I.D. tool | 4 | Parts catcher | |
| SUB – I.D. rotary tool | Working tools | ||
| Feed | Rapid feed rate | 30m/min | Levelling pad |
| Min. command unit | 0.0001mm | Signal warning light - 3 stage | |
| C axis Min. command unit (Main, Sub) | 0.0001° | Display language (CHN/ENG/FRA/GER/ITA/JPN/KOR/POL/RUS/SPA) | |
| Motor | Main spindle motor | 1.1 / 0.75kW | Optional Accessories |
| Cross drill motor | 0.4kW | O.D. tool post (6EA) | |
| Sub spindle motor | 1.1 / 0.75kW | 3-spindle drilling unit (Eccentric) | |
| $2 rotary motor | 0.4kW | Long drill holder | |
| Y1, Y1, Z1, Z2 axis feed motor | 0.5kW | Fixed guide bush | |
| Coolant pump (Main, Sub) | 0.25kW | Tap breakage detector | |
| Lubricant pump | 0.003kW | Tool air blow | |
| Dimensions and etc. | Main spindle center height | 1,000mm | Rear ejection unit (Ф7mm or less) |
| Input power capacity | 6.8KVA | Spindle tube liner for small part | |
| Air pressure, flow rate | 0.6MPa / 30L/min | Large-sized lubricant pump 1.8ℓ | |
| Coolant tank | 110L | Chip conveyor & Chip box | |
| WxDxH | 1,700 × 770 × 1,650mm | Medium / High pressure coolant | |
| Weight (Options included) | 1,500kg | Oil mist collector / Custom colors | |
| NC | NC System | MITSUBISHI M80 | Tooling |
| NC display | 8.4 Color TFT LCD | ||
| Memory capacity | 500KB | ||
| Number of tool offset | 256 sets |
