CNC-TAKANG DCM 2122A CNC Machine Specifications
Origin: Taiwan
| MODEL | DCM 2122A |
| TABLE | |
| Table size | 2200 × 2100 mm |
| T-slot | 22 × 150 × ? mm |
| Max table load | 8000 kgs |
| TRAVEL | |
| Travel | 2200 × 2100 × 900 mm |
| Spindle nose to table | 160–1060 mm |
| Center to column | 404 mm |
| Distance between columns | 2100 mm |
| SPINDLE | |
| Shank | ISO 50 |
| Inner dia | 100 mm |
| Speed | 8000 rpm |
| Draw bar force | 2000 kgf |
| Main motor | 15/18.5/30 kw |
| FEED | |
| Rapid | 12/16/20 m/min |
| Feed | 10000 mm/min |
| ATC | |
| ATC type | Disk/Chain |
| CAM type | ARM |
| Tool selection | Random |
| Tool storage | 24/32 |
| Tool dia | 115/127 mm (160/250) |
| Tool length | 350 mm |
| Tool weight | 20 kgs |
| MISC. | |
| Air | 6 kg/cm² |
| Hydraulic | 60 kg/cm² 40L |
| Voltage | 220 |
| Power | 50 KVA |
| Tank | 900 L |
| Weight | 23500 kgs |
| Height | 4500 mm |
| Floor | 6090 × 5300 mm |
- Air blast through spindle
- Air blast work piece (nose)
- Coolant flushing system
- Automatic lubrication system
- Work light
- Operation status light
- Screw type chip conveyor & chain type conveyor
- Chain type 32-tool ATC
- Gear head
- Cooling system
- Z axis pneumatic balance system
- Air gun/water gun
- MPG hand wheel
- Heat exchanger
- RS-232 interface
- Rigid tapping
- Spindle oil cooler
- Adjusting tools & box
- Leveling bolts & pads
- Operation & programming manual
- Semi-full splash safety guard
- Transformer
- Full splash guard
- Coolant through spindle
- Linear scales
- Auto tool length measurement
- Auto work piece measurement
- Manual universal head (90°)
- Auto universal head (90°)
- Rotary table
