CNC-TAKANG DCM 1942 CNC Machine Specifications
Origin: Taiwan
| MODEL | DCM 1942 |
| TABLE | |
| Table size | 3200 × 1700 mm |
| T-slot | 22 × 150 × ? mm |
| Max. table load | 12000 kgs |
| TRAVEL | |
| Travel ranges | 3200 × 1900 × 900 mm |
| Spindle nose to table | 160–1060 mm (OPT. Z=1100, 260–1360) |
| Spindle center to column | 404 mm |
| Distance between columns | 2000 mm |
| SPINDLE | |
| Shank | ISO 50 |
| Inner diameter | 100 mm |
| Speed | 8000 rpm |
| Draw bar force | 2000 kgf |
| Main motor | 15/18.5 con / 30 min kw |
| FEED | |
| Rapid feed | 10 / 16 / 20 m/min |
| Feed rate | 10000 mm/min |
| MITSUBISHI | HF703 7.0 kw |
| FANUC | α30 / 3000i 7.0 kw |
| SIEMENS | 1FK7 103 7.0 kw |
| FAGOR | FXM75.20 7.0 kw |
| HEIDENHAIN | QSY190D 9.6 kw |
| ATC | |
| ATC | Disk / Chain |
| CAM | ARM |
| Selection | Random |
| Storage | 24 / 32 |
| Max dia | 115/127 mm (160/250) |
| Max length | 350 mm |
| Max weight | 20 kgs |
| MISC. | |
| Air | 6 kg/cm² |
| Hydraulic | 60 kg/cm² 40L |
| Voltage | 220 |
| Power | 50 KVA |
| Tank | 900 L |
| Weight | 25000 kgs |
| Height | 4500 mm |
| Floor | 8130 × 5300 mm |
- Air blast through spindle
- Air blast work piece (nose)
- Coolant flushing system
- Automatic lubrication system
- Work light
- Operation status light
- Screw type chip conveyor & chain type conveyor
- Chain type 32-tool ATC
- Gear head
- Cooling system
- Z axis pneumatic balance system
- Air gun/water gun
- MPG hand wheel
- Heat exchanger
- RS-232 interface
- Rigid tapping
- Spindle oil cooler
- Adjusting tools & box
- Leveling bolts & pads
- Operation & programming manual
- Semi-full splash safety guard
- Transformer
- Full splash guard
- Coolant through spindle
- Linear scales
- Auto tool length measurement
- Auto work piece measurement
- Manual universal head (90°)
- Auto universal head (90°)
- Rotary table
