AXISCO PRECISION MACHINERY CHI-0813 CNC Machine Specifications
Origin: Taiwan
Category: Broaching Vertical 7.5 Ton
| Model | CHI-0813 |
| Broaching Force | 7.5 Ton |
| Broaching Stroke | 1300 mm |
| Cutting Speed (m/min, 60Hz) | 3–8 |
| Max. Hole Diameter | Ø80 mm |
| Max. Part Size | Ø350 mm |
| Driving Motor | 7.5 kW (10 HP) |
| Working Table Height | 2330 mm |
| Machining Height (with retrieval) | 4407 mm |
| Machining Height (without retrieval) | 3530 mm |
| Weight | 5500 kg |
