TRUMPF TruLaser 3030 – 2009 Model

Request a Quote



Metal length 3000 mm
Power 2.7 W
Metal width 1500 mm
Type CO₂
Option to cut tubes yes
Max thickness 15 mm
CNC yes
Travel X 3000 mm
Travel Y 1500 mm
Travel Z 115 mm
Max weight of the workpiece 710 kg
Length x width x height 9300.0 × 4600.0 × 2000.0
Weight 13200 kg
Worked hours 18873 hours
Hours under power 48857 hours
State good

Product / Type TRUMPF TC L 3030
Model Year 2009
Time (Laser Stand by) 48857 hr
Time (Resonator Beam ON) 18873 hr
Numeric Control SIEMENS SINUMERIK 840D
Laser Type TLF 2700 TURBO
Laser Power 2700 W
Movement X 3000 mm
Movement Y 1500 mm
Movement Z 115 mm
X Speed (MAX) 60 mt/min
Y Speed (MAX) 60 mt/min
Z Speed (MAX) 60 mt/min
X-Y Speed Simultaneous (MAX) 84 mt/min
Plate Thickness (MS, MAX) 15 mm
Workpiece Weight (MAX) 710 kg
Plate Thickness (SS, MAX) 8 mm
Plate Thickness (AL, MAX) 5 mm

Standard equipment:
– HI-LAS high-pressure-cutting
– Cutting head with 5″-Lense
– Cutting head with 7,5″-Lense
– Cutting head quick change device
– Metal sheet position detection system
– Programmable cutting-gas choice and pressure adjustment
– Microweld
– PMS Plasma Monitoring System
– Sprint-Las
– Capacitive height regulation (DIAS III)
– ContourLas
– AutoLas Plus
– Oil-Spray function
– Autom. pallet-changing
– Lit working chamber
– Small parts/waste conveyor
– Multi-chamber suction system
– Compact dust extractor
– Automatic switch-off
– Safety Light Barriers
– ToPs 100 lite programming system
– Tele service installation
– RJ 45 network connection
– 3,5”- Disk drive
– Operators manual
additional equipment
+ Rotolas
