Açıklama

Number of axes : 8
Number of spindles : 2
Number of turrets : 2

MAIN SPINDLE
Spindle nose : A2-5″
Spindle power : 7,5 [kW]
Spindle speeds : 6.000 [rpm]
Max. bar diameter : 42 [mm]
Max. turning length : 230 [mm]
C axis indexing precision : 0,001 [°]

COUNTER-SPINDLE
Spindle nose : A2-5″
Spindle power : 3,7 [kW]
Spindle speeds : 6.000 [rpm]
Max. bar diameter : 42 [mm]
Max. turning length : 100 [mm]
C axis indexing precision : 0,001 [°]
Z stroke : 360 [mm]
X stroke : 410 [mm]

TOOL BLOCK SYSTEM 1
Number of positions : 16
Number of motorized positions : 6
X/Z stroke : 140 x 230 [mm]
Y stroke : 410 [mm]
Tool type : ER20
Live tools speed : 4.000 [rpm]
Live tools power : 1 [kW]

TOOL BLOCK SYSTEM 2
Number of positions : 15
Number of motorized positions : 6
Y stroke : 410 [mm]
Tool type : ER 20
Live tools speed : 4.000 [rpm]
Live tools power : 1 [kW]

POWER SUPPLY
Supply voltage : 380 [V]
Total installed power : 20 [kVA]

WEIGHT & DIMENSIONS
Machine floor space : 3.465 x 1.654 [mm]
Machine height : 1.896 [mm]
Machine weight : 4.200 [kg]
