Açıklama
| Max wheel Gear Ø | 400 mm |
|---|---|
| Module + | 8 |
| CNC type | SIEMENS |
| Max spindle speed | 500 rpm |
| Max gear width | 310 mm |
| Length x width x height | 4680.0 × 2395.0 × 2515.0 |
| Weight | 6200 kg |
Technical data
Working capacity: max. diameter 400 mm
max. module 8
max. width of the gear wheel 310 mm
Min. 6
Axes distance between work-
piece and tool:
min. 20 mm
max 290 mm
Diam. 400 mm clamping table
Diameter of the table drill 80 mm
Diameter of the shaft of the workpiece 36 mm
Milling stroke 310 mm
Gear hob:
max. diameter 160 mm
min. diameter 160 mm
Max. strawberry mover. 120/126 mm
Milling cut speeds:
stepless
from 80 turns
up to 500 rpm
Flux:
stepless
axial from 0,4 mm / r
up to 7.5 mm / r
radial starting from 0.63 mm / r
up to 0.315 mm / r
tangential of 0.16 mm / r
up to 3.0 mm / r
Voltage 50 Hz 3x 220 Volt
Total power required 19 HP
Machine weight about 6200 kg
Overall dimensions machine:
Length 4680 mm
Width 2395 mm
Height 2515 mm
