Axis X | 1000 mm |
---|---|
Axis Y | 500 mm |
Axis Z | 510 mm |
Rotary table (4th axis) | no |
Type of CNC | FAGOR 8055 |
Table length | 1200 mm |
Table width | 500 mm |
Number of tool pockets | 18 |
Spindle taper | BT40 |
Max. spindle speed | 6000 rpm |
Spindle motor power | 13 kW |
Shaft travel (X, Y, Z): 1000X500x510 mm
Table: 1200 x 500 mm
Fast forward: 20m / min
Max spindle speed: 6,000 rpm
Max power head: 13 Kw
Tools charger: 18 tools
BT-40 Cone
Chip extractor
Control: Fagor 8055
Electronic steering wheel
Reading rules on all three axes
Internal cooling
