Açıklama
| Axis X | 660 mm |
|---|---|
| Axis Y | 350 mm |
| Axis Z | 380 mm |
| Rotary table (4th axis) | no |
| Type of CNC | Heidenhain 410 |
| Table length | 660 mm |
| Table width | 350 mm |
| Max. part weight | 100 kg |
| Number of tool pockets | 18 |
| Spindle taper | ISO 7388 (ISO40) |
| Max. spindle speed | 6000 rpm |
| Spindle motor power | 14 kW |
| Length x width x height | 2300.0 × 2400.0 × 2100.0 |
| Weight | 7000 kg |
Type: Vertical
CNC Control: Heidenhain 410
Number of axes: 3
Table dimensions: (2) 660 x 350 mm
X axis travel: 660 mm
Y axis travel: 350 mm
Z axis travel: 380 mm
X-axis rapid feed: 24 m / min
Y-axis rapid feed: 24 m / min
Z axis rapid feed: 20 m / min
Maximum weight on table: (2) 100 Kg.
Head cone: ISO 7388 (ISO40)
Spindle speed: 100 – 6000 rpm
Head power: 5.5 Kw – 7.5 Kw.
Net Weight: 7000 Kg.
Total power: 14 Kw.
Number of stations: 18 stations
Chip extractor
Electronic steering wheel
Does not include freight, transportation and assembly
