Açıklama
x-travel 600 mm
y-travel 500 mm
z-travel 500 mm
turning speed range – main spindle 20 – 14000 min/-1
spindle drive 18,9 (40%), 14 (100%) kW
tool taper Sk40 nach DIN 69871
chain magazin for 30 tools
control Siemens 840D SL ShopMill
table surface area 600 x 500 mm
swival range +/- B-Achse +110/-5 ° 360 °
Loading weight 400 kg
Options and accessories:
– Siemens 840D SL Operate 3D control
ShopMill Open user interface
DMG ERGOline Control, 19 ” screen
– NC swivel rotary table including table cooling
Rotary union for air and hydraulics
in the swivel table, 4-channel
Media connection on the front of the table
– Heat exchanger for spindle and table
– Active cooler for control cabinet
– Direct position measuring system
– full cabin
– Renishaw PP 60 optical (OMP60) infrared probe
– IKZ, paper band filter bar / 231 / min / tank 600l
including rotating lens, sealing air
Linear measuring system, bed flushing
– Cooling guns for chip flushing
– Scraper belt chip conveyor with cleaned slotted screen
– Documentation + screen text
– Expansion of virtual tool magazine to 499 tool places
