Açıklama
Metal length | 3000 mm |
---|---|
Power | 4400 W |
Metal width | 1500 mm |
Option to cut tubes | no |
Max thickness | 25 mm |
CNC | yes |
CNC type | Bystronic Byvision |
Travel X | 3048 mm |
Travel Y | 1524 mm |
Travel Z | 170 mm |
Power 4400w
Hours under power 31000 Hours
Laser Hours 13000 Hours
CNC Bystronic Byvision
XYZ strokes 3048 x 1524 x 170 mm
Max cutting thicknesses 25/20/12 (Steel / Stainless steel / Alu)
Total power consumption 52kW (machine) + 3kW (dust extractor)
cutting machine with safety advice for the operator during cutting, loading and unloading • automatic table changer • 2 cutting heads with 5 “+ 7.5” lenses • cutting control • Bypass-W • Cross -jet
